| Specification | Details |
|---|---|
| Product Type | WiFi 6 AX1800 Wireless Router |
| WiFi Standard | IEEE 802.11a/b/g/n/ac/ax |
| WiFi Class | AX1800 |
| WiFi Bands | Dual Band 2.4GHz + 5GHz |
| 2.4GHz WiFi Speed | Up to 573Mbps |
| 5GHz WiFi Speed | Up to 1201Mbps |
| Total WiFi Speed | Up to 1800Mbps |
| WiFi MIMO | 2×2 MIMO |
| WiFi Technologies | MU-MIMO, OFDMA, BSS Color, Beamforming, STBC, LDPC |
| Modulation | Up to 1024QAM |
| Connected Users | Up to 128 Users |
| Mesh WiFi | Supported |
| Fast Roaming | Supported |
| Band Steering | Supported |
| WiFi Relay | Supported |
| Ethernet Ports | 1× Gigabit WAN + 3× Gigabit LAN |
| WAN/LAN Speed | 10/100/1000Mbps Auto-Negotiation |
| Hardware Acceleration | HNAT Hardware Acceleration |
| Wired Forwarding | Up to 2Gbps Bidirectional |
| CPU | MediaTek MT7621A, Dual-Core MIPS, 880MHz |
| WiFi Chipset | MT7905DAN + MT7975DN |
| Memory | 256MB |
| Flash | 128MB |
| Antennas | 2× 2.4GHz 5dBi + 4× 5GHz 5dBi External Antennas |
| Working Modes | Router Mode / Bridge Mode |
| IPv4 / IPv6 | Supported |
| IPTV | Supported |
| VPN | PPTP / L2TP VPN Client |
| Security | WPA / WPA2 / WPA3, WPS, SSID Hiding, MAC/IP Filtering, URL Control, DDoS Protection |
| Network Features | DDNS, Port Forwarding, DMZ, Guest Network, Parental Control, ALG |
| Remote Management | WebUI / TR-069 |
| Power Supply | DC 12V / 1A |
| Operating Temperature | -10°C to +45°C |
| Storage Temperature | -20°C to +70°C |
| Dimensions | 195 × 125 × 180mm (Antennas Extended) 195 × 125 × 35mm (Antennas Folded) |
| Weight | 0.25kg |
