| Product Type |
4G/5G Indoor CPE / WiFi 6 Router |
| 5G Mode |
5G NR SA & NSA |
| 3GPP Release |
Release 16 |
| 5G NR Bands |
n1 / n3 / n5 / n7 / n8 / n20 / n28 / n38 / n40 / n41 / n77 / n78 |
| LTE FDD Bands |
B1 / B3 / B5 / B7 / B8 / B20 / B28 / B32 |
| LTE TDD Bands |
B38 / B40 / B41 / B42 / B43 |
| WCDMA Bands |
B1 / B5 / B8 |
| 5G NSA Speed |
Up to 5.47 Gbps DL / 825 Mbps UL |
| 5G SA Speed |
Up to 4.67 Gbps DL / 1.25 Gbps UL |
| LTE Speed |
Up to 1.6 Gbps DL / 211 Mbps UL |
| 5G Carrier Aggregation |
Up to 200 MHz, 2 DL CA / 2 UL CA |
| LTE Category |
DL Cat 19 / UL Cat 18 |
| LTE Carrier Aggregation |
Up to 5 DL CA / 2 UL CA |
| 5G Modulation |
DL/UL up to 256QAM |
| 5G MIMO |
DL 4×4 MIMO: n1/n3/n7/n28/n38/n40/n41/n77/n78; UL 2×2 MIMO: n40/n41/n77/n78 |
| Cellular Antennas |
2 × External + 2 × Internal 4G/5G Antennas, 4×4 MIMO |
| WiFi Standard |
WiFi 6, IEEE 802.11a/b/g/n/ac/ax |
| WiFi Class |
AX1800 |
| WiFi Bands |
Dual Band 2.4 GHz + 5 GHz |
| WiFi MIMO |
2×2 MU-MIMO |
| WiFi Users |
More than 32 users |
| WiFi Mesh |
Supported |
| SIM |
1 × SIM Slot; eSIM Optional |
| CPU |
UNISOC V620, Quad-Core ARM Cortex-A55, up to 2.0 GHz |
| Ethernet |
2 × Gigabit Ethernet Ports |
| Voice |
1 × RJ11, VoLTE (Optional) |
| USB |
1 × USB 2.0 |
| Operating System |
OpenWRT 24.10 |
| VPN |
Multiple VPN Tunnels Supported |
| Remote Management |
TR-069 / Central Management |
| Firmware Upgrade |
Local WebUI & Remote FOTA/OTA |
| Network Features |
Multiple APN, Static Routing, NAT, Port Mapping, Firewall |
| Power Supply |
DC 12V / 2A |
| Operating Temperature |
0°C to +50°C |
| Dimensions |
170 × 160 × 32 mm |
| Weight |
520 g |
| Installation |
Desktop |
