High performance 5G LTE router with sim card slot.
High speed internet 5G indoor WiFi CPE supports 2pcs RJ45 Ethernet ports.
Dual frequency 5G NR WiFi6 wireless router uses UNISOC UDX710 Chipset.
| Categoty | Item | Description |
| Hardware Specification |
WAN Standard | 3GPP 3Release 15 IEEE 802.3/802.3u/802.3z |
| LAN Standard | IEEE 802.3/802.3u/802.3z | |
| Wi-Fi Standard | IEEE 802.11a/b/g/n/ac/ax | |
| Chipset | UNISOC UDX710, Dual-core ARM Cortex A55MP @1.35 GHz IPQ5018 + QCN6102 |
|
| Frequency Band | 5G NR n1/ 3/ 5 /7/ 8/ 20/ 28/ 38/ 40/ 41/ 66 / 71/ 77/ 78 LTE FDD B1/ 2/ 3/ 4/ 5/ 7/ 8/ 20/ 28A/ 28B/ 66 LTE TDD B38/ 40/ 41 WCDMA B1/ 2/ 5/ 8 |
|
| 5G Transmission Rate | NR Sub6: 256QAM (DL/UL) SA Mode: 2 Gbps (DL)/ 1 Gbps (UL) NSA Mode: 2.6 Gbps (DL)/ 650 Mbps (UL) |
|
| LTE Transmission Rate | LTE: 256QAM (DL)/ 64QAM (UL) 600 Mbps( DL)/ 150 Mbps(UL) |
|
| WCDMA | 42Mbps(DL) / 11Mbps(UL) | |
| LED Indicator | 5G Wi-Fi/ 2.4G Wi-Fi/ Internet/ Power/ Signal Bar Indicator | |
| Interface | 1x GE WAN/LAN Port, 1x GE LAN Port, 1x SIM Slot (3FF), DC Socket | |
| Memory | ROM: 1Gb Nand Flash RAM: 4Gb LPDDR4X |
|
| Button | Reset | |
| Dimensions | 204 (H) × 158 (W) × 42 (T) mm | |
| Net Weight | 340 g | |
| Accessories | Ethernet cable x1, Power adapter x1, Quick start guide x1 | |
| Antenna | 5G/LTE Internal Main and Diversity Antennas x4 Dual Band Wi-Fi Antenna x2 |
|
| MIMO | 5G DL 4×4 MIMO: n1/ 3/ 7/ 28 / 38/ 40/ 41/ 77/ 78 5G UL 2x2 MIMO n38/ 40/ 41/ 77/ 78 LTE DL 2×2 MIMO n5/ 8/ 20 / 66/ 71 |
|
| Gain | 3G/4G/5G: 6dBi Wi-Fi: 3dBi |
|
| Output power | 5G NR: Class 3 (23 dBm ± 2 dB) HPUE Class 2 ( 26 dBm +2/-3 dB) for n41/78 LTE: Class 3 (23 dBm ± 2 dB) WCDMA: 23 dBm ± 2 dB WLAN: 24 dBm +1/-3 dB |
|
| Power Supply | AC 100V~240V,50Hz~60Hz, DC 12V 2A | |
| Power Consumption | < 18W | |
| Operating Temperature | ‘-10℃ ~ 55℃ | |
| Storage Temperature | -40℃ ~ 85℃ | |
| Humidity | 95% Non-Condensing | |
| Language | English (Customizable) | |
| Status indicator | Wi-Fi, USIM, Data, Signal Strength | |
| Internet Status | Status, Operator, Network Mode, Cell ID, RSRP, RSRQ | |
| Software Specification | WAN Info | Connect Mode, IP Address, Subnet Mask, DNS |
| LAN Info | IP Address, Subnet Mask, MAC Address | |
| Rate Info | DL/UL Data Rate, Online Time | |
| Device & SIM Info | Product Model, IMEI, Software Version, UICCID, IMSI | |
| Statistics | CPU Usage, Memory Usage, APN List, Bandwidth Statistics, Throughput Statistics, Device List | |
| Local Upgrade | Web Upgrade | |
| Auto Upgrade | FOTA Upgrade | |
| Network Mode | NAT, Bridge, Router | |
| DNS | Primary DNS, Secondary DNS | |
| NR/LTE Settings | NR/LTE Status, Connect Method | |
| Scan Mode | Full Band, Band Lock, PCI Lock, EARFCN Lock | |
| APN Management | Profile Name, APN Name, Authentication Type, PDN Type | |
| SIM Lock | Customizable | |
| LAN Settings | LAN Host Settings, DHCP Settings | |
| DMZ | ICMP Redirect | |
| Static Route | Limit to 10 | |
| Connection Mode | Dynamic WAN, Static WAN, LAN Only (by default) | |
| WLAN Settings | General Settings, SSID Profile | |
| WPS | PBC, Client PIN | |
| Access Management | White List, Black List | |
| Guest Network | 2.4G Guest, 5G Guest (Both Limit to 3 Guest SSID) | |
| Parental Controls Manager | Enable/ Disable | |
| Parental Controls List | Limit to 32 | |
| Firewall Switch | Enable/ Disable | |
| Firewall Rules | MAC Filtering, IP Filtering, URL Filtering, Port Forwarding, Port Triggering, Access Restriction, UPnP, DoS | |
| VPN Type | PPTP, L2TP, L2TP v3, GRE | |
| Security | IPsec (Available for L2TPv3 & GRE) | |
| TR069 | Standard TR069, TR098, TR111, TR143 | |
| SNMP | SNMP V2/V3 | |
| Diagnostics | Ping, Traceroute | |
| System Log | Local, Remote | |
| WEB Settings | HTTPS, Language, WAN access, HTTP port |
